INvision 5500i-SG


  • 2-1/4" structural silicone-glazed (SSG) mullions and intermediate horizontal framing members
  • 18 mm wide polyamide nylon thermal strut for energy efficiency and condensation resistance
  • Easy-to-install captured head and sill “can” receptors - Flush SSG sill and jamb receptors are available
  • No exterior unit wet sealing required; pressure-equalized, rain screen design
  • Less than 0.06 cfm/sqft air infiltration at 6.24 psf
  • 15 psf water test pressure; static and dynamic
  • Full AAMA 501 test protocol including interstory vertical and horizontal movement; thermal cycling
